Benefits
Bonds Difficult Plastics Without Primer
LSE-060WF is specifically developed to bond difficult low surface energy plastics such as polypropylene and TPO, eliminating primer in many applications and simplifying production.
Permanent Structural Bonding
Replaces screws, rivets, spot welds, and liquid adhesives while providing a clean, invisible bond line.
Excellent Initial Tack
Provides immediate handling strength and performs well even in low-temperature application environments.
Outstanding Environmental Durability
Maintains long-term bonding performance under UV exposure, moisture, humidity, and outdoor weather conditions.
Waterproof Sealing
The closed-cell acrylic foam seals against water, dust, and environmental contaminants.
Supports Lightweight Designs
Allows manufacturers to replace mechanical fasteners, reduce weight, and improve product aesthetics.
Technical Specifications
| Property | Specification |
|---|---|
| Product Name | 3M™ VHB™ LSE-060WF |
| Tape Type | Double-Sided Acrylic Foam Tape |
| Foam Color | White |
| Adhesive Type | Modified Acrylic |
| Foam Core | Very Conformable Closed-Cell Acrylic Foam |
| Thickness | 0.6 mm (25 mil) |
| Density | 710 kg/m³ |
| Release Liner | Red PE Film with 3M™ Print |
| Tensile Strength | 550 kPa |
| Overlap Shear Strength | 810 kPa |
| Indoor / Outdoor | Yes |
| UV Resistance | Excellent |
| Moisture Resistance | Excellent |
| Shelf Life | 24 Months |
| Processing Services | Slitting, Rewinding, Laminating, Die-Cutting, Kiss-Cutting |
Applications
Typical applications include:
- Polypropylene (PP) component bonding
- TPO and TPE trim attachment
- Plastic housings
- Automotive interior and exterior trim
- Appliance assembly
- Plastic signs and displays
- Outdoor power equipment
- Consumer electronics
- Transportation components
- Composite panel bonding
- Industrial equipment
- Plastic fabrication
- General structural bonding
Compatible Materials
| Excellent Compatibility | Good Compatibility | Testing Recommended |
|---|---|---|
| Polypropylene (PP) | Aluminum | PTFE |
| TPO | Stainless Steel | Silicone Rubber |
| TPE | Glass | Fluoropolymers |
| PA (Nylon) | Painted Metals | Untreated specialty plastics |
| HDPE | Composite Materials | — |
Note: LSE-060WF is specifically optimized for bonding low surface energy plastics while also providing excellent adhesion to many high- and medium-surface-energy materials.
Industries
- Automotive
- Appliance Manufacturing
- Plastics Processing
- Transportation
- Electronics
- Signage & Displays
- Outdoor Power Equipment
- General Industrial Manufacturing
- Consumer Products
Why Choose 3M™ VHB™ LSE-060WF?
Unlike conventional VHB tapes that perform best on metals and high-surface-energy materials, LSE-060WF is specifically engineered for difficult-to-bond plastics. It provides excellent adhesion to PP, TPO, TPE, and other LSE substrates without primer in many applications, while maintaining the long-term durability, weather resistance, and structural performance expected from the 3M™ VHB™ family.
Key advantages include:
- Designed specifically for LSE plastics
- Bonds PP and TPO without primer in many applications
- 0.6 mm conformable acrylic foam
- High initial tack
- Waterproof sealing
- Excellent UV and weather resistance
- Excellent vibration damping
- Suitable for indoor and outdoor use
- Precision die-cutting compatible
- OEM converting services available
Installation Guide
- Clean all bonding surfaces to remove dust, oil, and contaminants.
- In many LSE plastic applications, no primer is required.
- Apply the tape using firm, uniform pressure.
- Avoid repositioning after initial contact.
- Approximately 50% bond strength develops after 20 minutes, 90% after 24 hours, and 100% after 72 hours at room temperature.
- For critical applications, validate adhesion with production testing.
Storage
Store the tape in its original packaging.
Recommended storage conditions:
- Temperature: 16°C–27°C (60°F–80°F)
- Relative Humidity: 40%–60%
- Store in a clean, dry environment.
- Keep away from direct sunlight.
- Store rolls horizontally whenever possible.
- Follow FIFO (First-In, First-Out) inventory management.
- Shelf life: 24 months under recommended conditions.
Frequently Asked Questions (FAQ)
What is 3M™ VHB™ LSE-060WF used for?
It is designed for structural bonding of low surface energy plastics such as PP, TPO, TPE, and HDPE, while also bonding metals, composites, glass, and painted surfaces.
How thick is LSE-060WF?
The nominal thickness is 0.6 mm (25 mil).
Does it require Primer 94?
In many applications, no primer or adhesion promoter is required when bonding common LSE plastics, although application testing is recommended.
Which plastics can it bond?
It bonds PP, TPO, TPE, PA (Nylon), HDPE, ABS, and many engineering plastics, as well as metals and composites.
Is it suitable for outdoor use?
Yes. It offers excellent resistance to UV exposure, moisture, temperature cycling, and weathering.
What is the difference between LSE-060WF and 5952?
- LSE-060WF is optimized for low surface energy plastics and often eliminates the need for primer.
- 5952 is designed primarily for metals, painted surfaces, and medium- to low-surface-energy materials, but may require primer on some difficult plastics.
Can LSE-060WF be die-cut?
Yes. Guangdong Yousan provides precision die-cutting, slitting, laminating, rewinding, kiss-cutting, and custom OEM converting services.
Downloads
Available upon request:
- 3M™ VHB™ LSE-060WF Technical Data Sheet (TDS)
- Safety Data Sheet (SDS)
- Product Brochure
- Application Guide
- Die-Cutting Capability Guide
Please contact our sales team if you require the latest technical documentation.
