Benefits
Strong Permanent Bond
Provides durable structural bonding that replaces screws, rivets, and welding while maintaining an attractive appearance.
Excellent Multi-Material Bonding
Designed to bond aluminum, stainless steel, galvanized steel, glass, acrylic, polycarbonate, ABS, and many painted substrates.
Faster Manufacturing
Pressure-sensitive adhesive eliminates curing time and simplifies assembly processes.
Outstanding Environmental Resistance
Maintains reliable performance under UV exposure, moisture, humidity, and outdoor weather conditions.
Shock & Vibration Absorption
The viscoelastic acrylic foam absorbs impact and distributes stress evenly, improving assembly durability.
Waterproof Sealing
Closed-cell acrylic foam creates an effective barrier against water, dust, and environmental contaminants.
Technical Specifications
| Property | Specification |
|---|---|
| Product Name | 3M™ VHB™ GPL-080GF |
| Tape Type | Double-Sided Acrylic Foam Tape |
| Foam Color | Gray |
| Adhesive Type | Modified Acrylic |
| Foam Type | Firm Closed-Cell Acrylic Foam |
| Thickness | 0.80 mm (32 mil) |
| Liner | 3M™ Red PE Film Liner |
| Density | Approx. 720 kg/m³ |
| Short-Term Temperature Resistance | 230°C (450°F) |
| Long-Term Temperature Resistance | 121°C (250°F) |
| Indoor / Outdoor | Yes |
| UV Resistance | Excellent |
| Moisture Resistance | Excellent |
| Weather Resistance | Excellent |
| Converting Services | Slitting, Rewinding, Laminating, Die-Cutting, Kiss-Cutting |
Refer to the official 3M Technical Data Sheet for complete technical performance data.
Applications
Typical applications include:
- Metal panel bonding
- Decorative trim attachment
- Appliance assembly
- Electronic equipment assembly
- Architectural panel bonding
- Transportation interior assembly
- HVAC equipment
- Glass-to-metal bonding
- Plastic housing assembly
- Signage and display fabrication
- Control panel installation
- Solar equipment assembly
- Industrial machinery
- Nameplate attachment
- General industrial structural bonding
Compatible Materials
| Excellent Compatibility | Good Compatibility | Testing Recommended |
|---|---|---|
| Aluminum | Painted Metals | Polypropylene (PP) |
| Stainless Steel | ABS | Polyethylene (PE) |
| Glass | Acrylic (PMMA) | PTFE |
| Polycarbonate (PC) | Composite Materials | Silicone Rubber |
| Galvanized Steel | PVC | Untreated LSE Plastics |
Note: GPL-080GF performs best on high surface energy (HSE) and medium surface energy (MSE) materials. Adhesion testing is recommended for low surface energy plastics before production.
Industries
- Automotive
- Electronics
- Appliance Manufacturing
- Construction
- Transportation
- Signage & Displays
- HVAC
- Renewable Energy
- Industrial Equipment
- Metal Fabrication
Why Choose 3M™ VHB™ GPL-080GF?
3M™ VHB™ GPL-080GF combines strong structural bonding, excellent environmental durability, and efficient assembly in a versatile 0.80 mm thickness suitable for a wide range of industrial applications.
Key advantages include:
- 0.80 mm gray firm acrylic foam
- Modified acrylic adhesive
- High initial tack
- Excellent peel and shear strength
- Permanent structural bonding
- Waterproof sealing
- UV and weather resistance
- Excellent vibration damping
- Supports automated manufacturing
- Custom die-cutting and OEM converting services
Installation Guide
- Clean all bonding surfaces using isopropyl alcohol or an approved cleaner.
- Ensure all substrates are clean and dry.
- Apply the tape using firm, even pressure.
- Avoid repositioning after initial contact.
- Allow 24–72 hours for maximum bond strength to develop.
- Perform production testing before full-scale manufacturing.
Storage
Store the tape in its original packaging under recommended conditions.
Storage conditions:
- Temperature: 16°C–27°C (60°F–80°F)
- Relative Humidity: 40%–60%
- Keep away from direct sunlight.
- Store in a cool, dry environment.
- Store rolls horizontally whenever possible.
- Follow FIFO (First-In, First-Out) inventory management.
Frequently Asked Questions (FAQ)
What is 3M™ VHB™ GPL-080GF used for?
It is used for permanent structural bonding in automotive, appliances, electronics, signage, transportation, construction, and industrial manufacturing.
How thick is GPL-080GF?
The tape has a nominal thickness of 0.80 mm (32 mil).
What materials can GPL-080GF bond?
It bonds aluminum, stainless steel, galvanized steel, glass, painted metals, ABS, acrylic, polycarbonate, and many medium surface energy plastics.
Can GPL-080GF replace screws or rivets?
Yes. It is designed to replace many mechanical fasteners and liquid adhesives while improving appearance and simplifying assembly.
Is GPL-080GF suitable for outdoor use?
Yes. It offers excellent resistance to UV exposure, moisture, weathering, and temperature cycling.
Can GPL-080GF be die-cut?
Yes. Guangdong Yousan provides slitting, laminating, rewinding, precision die-cutting, kiss-cutting, and custom converting services.
What is the difference between GPL-080GF and GPH-060GF?
GPL-080GF is a general-purpose structural bonding tape with strong multi-material adhesion, while GPH-060GF is optimized for high-temperature manufacturing, including powder coating and paint-bake processes.
Do you offer OEM services?
Yes. We provide OEM packaging, custom roll widths, printed cores, die-cut parts, and engineering support.
Downloads
Available upon request:
- 3M™ VHB™ GPL-080GF Technical Data Sheet (TDS)
- Safety Data Sheet (SDS)
- Product Brochure
- Application Guide
- Die-Cutting Capability Guide
Please contact our sales team if you require the latest technical documentation.
