Benefits
- Reliable Material Lamination: Provides consistent adhesion for bonding foam, felt, and other flexible materials.
- Good Surface Wetting: Helps the adhesive make effective contact with different foam and felt surfaces.
- Efficient Converting: Suitable for further processing, including slitting, laminating, and die-cutting.
- Translucent Appearance: Helps maintain a clean appearance in selected assembly applications.
- Flexible Material Compatibility: Can be evaluated for various foam and felt constructions according to substrate properties and application requirements.
- Custom Processing Options: Can be converted into rolls, sheets, strips, or die-cut adhesive components.
Technical Specifications
| Property | Specification |
|---|---|
| Product Name | Tesa 60996 |
| Product Version | PV44 / PV43 |
| Adhesive Type | Tackified acrylic |
| Backing Material | Non-woven |
| Total Thickness | 130 μm |
| Tape Color | Translucent |
| Liner Material | PE-coated paper |
| Liner Color | White |
| Tack | Very good |
| PV43 Liner | White PE-coated paper with blue tesa logo |
| PV44 Liner | White PE-coated paper, non-printed |
| Application | Foam and felt lamination |
| Adhesion to Steel, Initial | 9 N/cm |
| Adhesion to Steel, After 14 Days | 14.1 N/cm |
The listed technical values are representative average values and should not be treated as product specifications. Final product selection should be based on the latest technical data sheet and application testing.
Applications
Tesa 60996 PV44/43 is primarily designed for:
- Foam lamination
- Felt lamination
- Bonding flexible foam materials
- Bonding felt materials
- Laminating cushioning materials
- Manufacturing adhesive-backed foam components
- Manufacturing adhesive-backed felt components
- Custom adhesive component converting
The suitability of the tape should be evaluated according to the foam or felt type, surface structure, thickness, compression characteristics, and required bonding performance.
Compatible Materials
Tesa 60996 may be evaluated for use with:
- Polyurethane (PU) foam
- Polyethylene (PE) foam
- EVA foam
- Polyester felt
- Nonwoven felt
- Textile-based felt
- Cushioning materials
- Flexible polymer materials
Actual compatibility depends on the material formulation, surface treatment, porosity, roughness, and application conditions. Testing is recommended before mass production.
Industries
Potential industries and application sectors include:
- Automotive interior components
- Furniture and upholstery
- Consumer electronics
- Appliance manufacturing
- HVAC and insulation
- Industrial equipment
- Packaging and protective materials
- Acoustic and cushioning material processing
- Foam and felt converting
- Custom adhesive component manufacturing
The product should be selected based on the specific requirements of each application, including adhesion, aging resistance, temperature exposure, and substrate compatibility.
Why Choose tesa 60996 PV44/43?
- Designed for Foam and Felt Lamination: Developed for applications involving foam and felt materials.
- Tackified Acrylic Adhesive: Provides good initial tack and reliable adhesion performance on suitable substrates.
- Excellent Wetting: Supports adhesive contact with different foam and felt surfaces.
- Good Converting Performance: Suitable for professional slitting, laminating, and die-cutting processes.
- Flexible Liner Options: PV43 and PV44 versions support different handling and processing preferences.
- Custom Converting Support: Yousan can evaluate slitting, rewinding, laminating, kiss-cutting, and custom die-cutting requirements based on project specifications.
Yousan provides adhesive tape converting and customized adhesive component solutions for industrial and commercial applications. Product selection and processing conditions should be confirmed according to the original tesa material and customer requirements.
Installation Guide
1. Prepare the Substrate
Ensure that the bonding surfaces are clean, dry, and free from dust, oil, grease, and other contaminants.
2. Check Material Compatibility
Test the tape with the actual foam, felt, or other substrate before production. Pay particular attention to porous, rough, low-surface-energy, or heavily textured materials.
3. Apply the Tape
Apply the tape evenly to one surface while avoiding wrinkles, air pockets, and excessive stretching.
4. Apply Firm Pressure
Use uniform pressure to improve contact between the adhesive and the substrate. A suitable roller or laminating process may be used depending on the material structure.
5. Remove the Liner
Peel off the PV43 or PV44 liner carefully before bonding the second substrate.
6. Complete the Lamination
Align the materials accurately and apply consistent pressure across the bonding area. Allow sufficient dwell time before applying significant stress to the assembly.
Processing parameters should be validated according to the substrate type, production speed, pressure, and required bond strength.
Storage
- Store the tape in its original packaging.
- Keep the product in a clean and dry environment.
- Protect it from direct sunlight, excessive heat, and moisture.
- Avoid contamination of the adhesive surface.
- Store rolls flat or according to the supplier’s recommended handling instructions.
- Follow the latest tesa storage and shelf-life recommendations.
- Inspect the material before use, particularly after extended storage or exposure to unsuitable conditions.
FAQ
1. What is tesa 60996 PV44/43?
tesa 60996 PV44/43 is a translucent double-sided non-woven tape with tackified acrylic adhesive, mainly designed for foam and felt lamination.
2. What is the thickness of tesa 60996?
The total tape thickness is approximately 130 μm.
3. What is the difference between PV43 and PV44?
Both versions use a white PE-coated paper liner:
- PV43: White PE-coated paper liner with a blue tesa logo.
- PV44: White PE-coated paper liner without printing.
4. Is tesa 60996 suitable for foam lamination?
Yes. Foam lamination is one of the product’s primary application fields. Compatibility should be verified with the specific foam type and surface structure.
5. Can tesa 60996 be used for felt bonding?
Yes. The product is designed for lamination of different felt materials, subject to application testing.
6. Is tesa 60996 suitable for die-cutting?
The product has very good converting properties and may be considered for slitting, laminating, and die-cutting. The final processing method depends on the design, tolerance, liner, and production requirements.
7. Is tesa 60996 suitable for PE or PP materials?
The product shows adhesion to PE and PP, but the adhesion level may vary depending on the substrate surface and formulation. Testing is recommended before production.
8. Can Yousan provide custom converting?
Yousan can evaluate custom slitting, rewinding, laminating, kiss-cutting, and die-cutting services according to the customer’s drawings, dimensions, and application requirements.
9. Is tesa 60996 suitable for high-temperature applications?
The publicly available product information does not establish it as a high-temperature tape. Temperature resistance and long-term performance should be confirmed using the latest TDS and application testing.
10. How can I select between tesa 60996 PV43 and PV44?
The primary difference is the liner printing. PV43 has a blue tesa logo, while PV44 uses a non-printed liner. Selection may depend on processing preferences and customer requirements.
Downloads
Available upon request:
- Tesa 60999 PV44/43 Technical Data Sheet (TDS)
- Safety Data Sheet (SDS)
- Product Brochure
- Precision Die-Cutting Capability Guide
Please contact our sales team if you require the latest technical documentation.
