Benefits
Barefoot-Friendly Surface
The fine-textured resilient surface provides slip resistance without the aggressive feel associated with coarse mineral abrasive tapes.
Designed for Wet Conditions
The water-resistant acrylic adhesive is specifically designed for wet-area applications.
Transparent Appearance
The clear construction allows the underlying surface to remain visible, making it suitable for applications where appearance is important.
Fine Texture
The fine-textured surface provides traction while maintaining a relatively smooth and comfortable feel.
Suitable for Recreational and Wet Areas
220 is particularly appropriate for showers, tubs, swimming pool surroundings, hot tubs and other barefoot environments.
Customizable
3M indicates that custom shapes and sizes are available, allowing the material to be converted for specific application requirements.
Technical Specifications
| Property | 3M™ Safety-Walk™ 220 |
|---|---|
| Product Series | Fine Resilient 200 Series |
| Product Number | 220 |
| Color | Clear / Transparent |
| Anti-Slip Material | Vinyl |
| Surface | Fine-textured, resilient |
| Mineral Abrasive | No |
| Adhesive | Acrylic |
| Adhesive Type | Pressure-sensitive |
| Adhesive Characteristic | Water-resistant |
| Backing / Carrier | Configuration dependent |
| Traffic | Wet / Barefoot traffic |
| Application Environment | Wet areas |
3M’s current product listing confirms vinyl anti-slip material, transparent color, acrylic adhesive and poly-coated paper carrier for one current 1220 mm × 18.3 m configuration. Another current 50.8 mm × 18.3 m configuration lists vinyl carrier material. Therefore, the exact carrier/liner construction should be specified according to the SKU you are selling rather than applying one construction to every 220 configuration.
Applications
- Showers
- Bathtubs
- Swimming pool areas
- Around hot tubs
- Spa areas
- Locker rooms
- Wet floors
- Barefoot walkways
- Surfboards
- Water sports equipment
- Recreational facilities
- Marine applications
- Shower steps
- Pool access areas
- Other wet, barefoot-traffic surfaces
3M specifically identifies showers, tubs, surfboards, and areas around hot tubs and pools as applications for 220.
Compatible Materials
3M 220 is intended for properly prepared, clean and dry surfaces suitable for adhesive bonding, such as:
- Fiberglass
- Acrylic
- Smooth plastics
- Painted surfaces
- Metal
- Stainless steel
- Aluminum
- Smooth flooring
- Shower surfaces
- Bathtub surfaces
- Pool equipment
- Recreational equipment
- Other suitable smooth hard substrates
Before application, the surface should be free from:
- Oil
- Grease
- Dust
- Dirt
- Wax
- Soap residue
- Loose coatings
- Other contaminants
For porous or difficult-to-bond substrates, appropriate surface preparation and primer may be required.
Industries
- Swimming Pools & Aquatic Facilities
- Hospitality
- Hotels & Resorts
- Spas & Wellness
- Fitness & Recreation
- Marine
- Water Sports
- Commercial Buildings
- Property Management
- Facility Management
- Recreational Facilities
- Public Facilities
Why Choose
3M™ Safety-Walk™ 220 is a better choice when the application requires wet-area slip resistance, barefoot comfort and a transparent appearance.
Its positioning is fundamentally different from the 600 Series products you have just created:
| Product | Series | Surface | Main Traffic |
|---|---|---|---|
| 3M 220 | 200 Series | Fine-textured, non-mineral vinyl | Wet / Barefoot |
| 3M 370 | 300 Series | Medium-resilient, non-mineral | Barefoot / Light shoe |
| 3M 610 | 600 Series | Mineral-coated abrasive | Light–Heavy shoe |
| 3M 620 | 600 Series | Clear mineral-coated | Light–Heavy shoe |
| 3M 630 | 600 Series | Safety Yellow mineral-coated | Light–Heavy shoe |
3M’s own selection guide places 220 in the Fine Resilient 200 Series, specifically emphasizing wet barefoot applications, while 370 belongs to the Medium Resilient 300 Series.
Installation Guide
1. Prepare the surface
Clean the application area thoroughly and remove dirt, grease, oil, soap residue and other contaminants.
2. Ensure the surface is dry
Although 220 is designed for wet environments, the surface should be dry during installation to achieve proper adhesive contact.
3. Measure the application area
Determine the required length and shape before removing the liner.
4. Cut the material
Cut 220 to the required size or use a pre-converted shape.
5. Position carefully
Place the tape accurately before applying firm pressure.
6. Apply gradually
Press the material down progressively to minimize air entrapment.
7. Apply firm pressure
Use a suitable roller to ensure full adhesive contact with the substrate.
8. Seal vulnerable edges if necessary
For demanding wet applications, exposed edges should be evaluated and appropriately protected.
9. Allow adequate bonding time
Avoid unnecessary exposure to water or heavy use immediately after installation.
Proper surface preparation is particularly important in wet environments because water and contaminants can reduce adhesive performance.
Storage
Store 3M™ Safety-Walk™ 220 in its original packaging in a clean, dry environment.
Avoid:
- Direct sunlight
- Excessive heat
- High humidity
- Water exposure
- Dust and contamination
- Pressure or deformation of the roll
Keep the adhesive liner intact until installation.
For commercial inventory, follow the storage conditions and shelf-life requirements applicable to the exact 220 SKU.
FAQ
Q1: What is 3M 220 anti-slip tape?
3M 220 is a clear, fine-textured, non-mineral anti-slip tape from the Safety-Walk 200 Series.
Q2: Is 3M 220 transparent?
Yes. 3M identifies 220 as Clear / Transparent.
Q3: Is 3M 220 a mineral abrasive tape?
No. It uses a fine-textured resilient vinyl surface rather than a mineral abrasive coating.
Q4: Is 3M 220 suitable for barefoot use?
Yes. It is specifically designed for wet, barefoot-traffic areas.
Q5: Can 3M 220 be used in showers?
Yes. Showers are specifically listed by 3M as an application.
Q6: Can 3M 220 be used in bathtubs?
Yes. 3M specifically lists tubs among its applications.
Q7: Can 3M 220 be used around swimming pools?
Yes. Areas around hot tubs and pools are specifically listed applications.
Q8: What is the difference between 3M 220 and 3M 370?
Both are non-mineral Safety-Walk products designed with user comfort in mind, but 220 is Fine Resilient 200 Series and specifically targeted at wet/barefoot areas, while 370 is Medium Resilient 300 Series for barefoot and light shoe traffic.
Q9: What is the difference between 3M 220 and 3M 620?
Both can be transparent, but their construction and positioning are different. 220 is a fine-textured, non-mineral vinyl product for wet barefoot traffic, while 620 is a mineral-coated General Purpose 600 Series product for light to heavy shoe traffic.
Q10: Can 3M 220 be used on stairs?
It can be considered for suitable wet or barefoot stair applications, but the exact surface and traffic conditions should be evaluated. The 200 Series is primarily positioned around wet barefoot applications.
Q11: Can 3M 220 be die-cut?
Yes. 3M states that custom shapes and sizes are available.
Downloads
Available upon request:
- 3M 220 Anti Slip Tape Technical Data Sheet (TDS)
- Safety Data Sheet (SDS)
- Adhesive Tape Selection Guide
- Product Brochure
- Die-Cutting Capability Guide
Please contact our sales team if you require the latest technical documentation.
