Benefits
- Reliable mounting: Provides dependable bonding for suitable substrates.
- Conformability: Flexible PE foam adapts to slightly uneven surfaces.
- Gap compensation: Helps accommodate minor gaps between mating components.
- Cushioning: Provides a resilient interface between assembled components.
- Clean appearance: White foam construction integrates well with white and light-colored parts.
- Efficient assembly: Double-sided adhesive construction can reduce the need for mechanical fasteners in suitable applications.
- Custom converting: Can be supplied as narrow rolls, strips, pads, gaskets, and precision die-cut components.
Technical Specifications
| Property | 3M™ 4496 White |
|---|---|
| Product Type | Double Coated PE Foam Tape |
| Foam Carrier | Polyethylene (PE) Foam |
| Color | White |
| Adhesive | Pressure-Sensitive Adhesive |
| Construction | Double Coated |
| Primary Functions | Mounting, bonding, sealing, cushioning |
| Form | Roll / Converted Parts |
| Converting | Slitting, rewinding, laminating, die-cutting |
| Thickness | 1.47mm |
| Width | According to roll specification / customizable |
| Length | According to roll specification |
| Temperature Resistance | Refer to current 3M™ technical data |
Technical note: Exact thickness, adhesive properties, liner construction, adhesion values, temperature resistance, and other numerical specifications should be verified against the latest 3M™ 4496 White technical documentation for the specific configuration.
Applications
- General component mounting
- Panel mounting
- Trim and profile attachment
- Nameplate mounting
- Sign and display mounting
- Decorative component mounting
- Appliance assembly
- Furniture assembly
- Industrial component bonding
- Lightweight component mounting
- Sealing and gap filling
- Cushioning between components
- General assembly
- Custom die-cut adhesive components
Compatible Materials
Depending on surface condition and application requirements, 3M™ 4496 White may be considered for suitable combinations of:
- Metal
- Aluminum
- Painted metal
- Glass
- ABS
- PVC
- Acrylic
- Polycarbonate (PC)
- Plastic components
- Wood and engineered wood
- Decorative panels
- Other suitable substrates after application testing
For low-surface-energy plastics such as PE and PP, application testing is recommended because adhesion can vary according to substrate formulation, additives, surface treatment, and environmental conditions.
Industries
- Automotive
- Appliance
- Electronics
- Furniture
- Sign & Display
- Building & Construction
- HVAC
- Industrial Equipment
- Consumer Products
- General Manufacturing
- Component Assembly
Why Choose
3M™ 4496 White Double Coated Polyethylene Foam Tape provides a practical PE foam solution for mounting, bonding, sealing, cushioning, and general assembly applications where a white double-coated foam tape is preferred.
Its white PE foam construction can provide a visually integrated appearance with light-colored components. Yousan supports industrial customers with custom slitting, rewinding, laminating, and precision die-cutting, allowing the tape to be supplied in rolls, narrow strips, adhesive pads, gaskets, and custom die-cut shapes.
Installation Guide
- Clean the surfaces: Remove dust, oil, grease, moisture, and other contaminants.
- Dry the surfaces: Ensure both substrates are completely dry.
- Check compatibility: Test the tape on the actual substrates and surface finishes.
- Apply the tape: Apply 3M™ 4496 evenly without excessive stretching.
- Apply pressure: Use a roller or suitable tool to apply firm and uniform pressure.
- Remove the liner: Carefully remove the release liner without contaminating the adhesive.
- Position the components: Align the mating surfaces accurately.
- Apply pressure: Press the components together to establish intimate adhesive contact.
- Allow dwell time: Allow sufficient time for the adhesive bond to develop before applying significant loads.
Storage
Store 3M™ 4496 White in its original packaging in a clean and dry environment.
Protect the tape from direct sunlight, excessive heat, moisture, dust, and contamination.
For specific storage temperature, relative humidity, shelf life, and recommended storage period, refer to the latest 3M™ 4496 technical documentation.
FAQ
Q1: What is 3M™ 4496 White?
3M™ 4496 White is a white double-coated polyethylene (PE) foam tape designed for mounting, bonding, sealing, cushioning, and general assembly applications.
Q2: Is 3M™ 4496 White a double-sided foam tape?
Yes. It features a PE foam carrier with adhesive coated on both sides.
Q3: What is the difference between 4496 Black and 4496 White?
The primary visible difference is the foam color: 4496 Black uses black PE foam, while 4496 White uses white PE foam. Always check the applicable 3M technical documentation for configuration-specific differences.
Q4: Is 3M™ 4496 White a VHB™ tape?
No. 3M™ 4496 White is a PE foam tape and should not be classified as a 3M™ VHB™ acrylic foam tape.
Q5: Can 3M™ 4496 White be used for plastic bonding?
It may be suitable for various plastic substrates. Adhesion depends on the plastic type, surface energy, additives, surface condition, and application environment. Testing is recommended before production use.
Q6: Can 3M™ 4496 White be used for sealing?
It can be considered for suitable sealing and gap-filling applications. Actual sealing performance depends on joint design, compression, substrates, environmental exposure, and required service life.
Q7: Can 3M™ 4496 White be die-cut?
Yes. Yousan provides slitting, rewinding, laminating, and precision die-cutting for customized adhesive components, subject to the specific product configuration.
Q8: Can Yousan provide custom-width 4496 White?
Yes. Yousan can supply customized roll widths, narrow strips, and precision die-cut adhesive parts according to customer requirements.
Downloads
Available upon request:
- 3M 4496 White PE Foam Tape Technical Data Sheet (TDS)
- Safety Data Sheet (SDS)
- Product Brochure
- Die-Cutting Capability Guide
Please contact our sales team if you require the latest technical documentation.
