Benefits
High Shear Strength
3M™ Adhesive 100 is a firm acrylic pressure-sensitive adhesive system designed to provide high ultimate bond strength and very high shear holding power. The 4016 construction provides strong holding performance for mounting applications.
Conformable Foam Construction
The flexible urethane foam carrier can conform to surface irregularities and helps maintain contact between the bonded surfaces.
Long-Term Holding
3M reports long-term holding capability at temperatures up to 104°C (220°F) under the specified conditions.
Vibration Damping
The urethane foam carrier helps dampen vibration, making the tape suitable for selected mounting and joining applications where some cushioning is beneficial.
Easy Converting
The tape’s densified kraft paper liner supports industrial converting operations, including die-cutting and automated dispensing.
Technical Specifications
| Property | Typical Value |
|---|---|
| Product | 3M™ Double Coated Urethane Foam Tape 4016 |
| Tape Type | Double-sided foam tape |
| Adhesive | 3M™ Adhesive 100 |
| Adhesive Type | Acrylic pressure-sensitive adhesive |
| Carrier | Polyurethane Foam |
| Foam Structure | Open Cell |
| Color | Natural / Off-White |
| Nominal Thickness | 1.6 mm (0.0625 in / 62.5 mil) |
| Thickness Range | 1.142–2.03 mm (45–80 mil) |
| Foam Density | 175 kg/m³ (11 lb/ft³) |
| Liner | Densified Kraft Paper |
| Liner Color | Green Plaid |
| Liner Thickness | 0.08 mm (3 mil) |
| Normal Tensile | 345 kPa (50 psi) |
| Static Shear @ 23°C | 1,500 g |
| Static Shear @ 49°C | 1,000 g |
| Static Shear @ 66°C | 750 g |
| Static Shear @ 93°C | 750 g |
| Long-Term Temperature Resistance | Up to 104°C (220°F) |
| Short-Term Temperature Resistance | Up to 193°C (380°F) |
The values above are representative or typical values and should not be used as specification limits. Actual performance depends on substrate, surface preparation, bond area, environmental conditions, load and application design.
Applications
3M™ Double Coated Urethane Foam Tape 4016 is suitable for:
- Interior sign mounting
- Nameplate mounting
- Dispenser mounting
- Air freshener mounting
- Acoustic panel attachment
- Wire clip attachment
- Corner protector mounting
- Interior component assembly
- General mounting applications
- Joining and holding applications
- Cushioning and vibration-damping applications
- Industrial assembly
- Die-cut mounting components
For exterior applications, 3M recommends applications where the tape is protected from direct environmental exposure.
Compatible Materials
3M™ Double Coated Urethane Foam Tape 4016 offers good adhesion to a variety of surfaces, particularly:
- Metals
- Aluminum
- High surface energy plastics
- Rigid plastic components
- Painted surfaces, subject to testing
- Industrial substrates
- Signage materials
- Nameplate materials
- Acoustic panel surfaces
Substrate compatibility should always be evaluated under actual application conditions, especially for low surface energy plastics, powder-coated surfaces, textured materials or contaminated substrates.
Industries
- Industrial Manufacturing
- General Manufacturing
- Signage
- Appliance Manufacturing
- Construction
- Interior Design
- Building Products
- Electronics
- HVAC
- Commercial Equipment
- Furniture
- Display and POS
- Packaging Equipment
Why Choose 3M™ Double Coated Urethane Foam Tape 4016?
High Shear Holding Power
The combination of the flexible polyurethane foam carrier and 3M™ Adhesive 100 provides high shear holding strength for demanding mounting applications.
Flexible Foam Carrier
The open-cell urethane foam can conform to surface irregularities and help maintain contact between mating surfaces.
Reliable Acrylic Adhesive
3M™ Adhesive 100 provides high ultimate bond strength, high shear holding power and good temperature and solvent resistance.
Vibration Damping
The foam construction helps dampen vibration and provides cushioning between assembled components.
Industrial Converting
The green plaid densified kraft liner helps support die-cutting and automated dispensing processes.
Versatile Mounting Solution
4016 can be used for a broad range of mounting, joining and holding applications where a flexible foam tape with high shear strength is required.
Installation Guide
1. Clean the Surface
Remove dust, oil, grease, moisture and other contaminants from the bonding surfaces.
For best results, the substrate should be clean, dry and free from contamination.
2. Prepare the Tape
Cut the tape to the required length or shape.
Avoid touching the adhesive surface after removing the liner.
3. Apply the Tape
Apply the tape to the first substrate and press firmly to ensure good contact.
4. Remove the Liner
Peel away the green plaid release liner without contaminating the exposed adhesive.
5. Join the Components
Position the second substrate carefully and bring the surfaces together.
Avoid unnecessary repositioning after contact.
6. Apply Pressure
Apply firm, even pressure over the entire bonded area.
Adequate pressure helps maximize adhesive contact and bond development.
7. Allow Bond Development
Bond strength increases with time as the adhesive develops its ultimate adhesion. Actual bond development depends on substrate, temperature, pressure and dwell time.
Important: For critical applications, validate the complete assembly under actual operating conditions before production use.
Storage
Store 3M™ Double Coated Urethane Foam Tape 4016 in its original packaging in a clean and dry environment.
Protect the material from excessive heat, direct sunlight, moisture, dust and contamination.
The 3M technical documentation should be consulted for the applicable shelf-life and storage requirements for the specific product configuration.
FAQ
Q1: What is 3M™ Double Coated Urethane Foam Tape 4016?
3M 4016 is a double-sided, 1.6 mm thick urethane foam tape using a flexible open-cell polyurethane foam carrier and 3M™ Adhesive 100 acrylic adhesive.
Q2: What is the thickness of 3M 4016?
The nominal thickness is 1.6 mm (0.0625 in / 62.5 mil). The current 3M TDS lists a typical thickness range of 1.142–2.03 mm.
Q3: Is 3M 4016 double-sided?
Yes. Adhesive is coated on both sides of the polyurethane foam carrier.
Q4: What adhesive does 3M 4016 use?
3M 4016 uses 3M™ Adhesive 100, a firm acrylic pressure-sensitive adhesive system designed for high ultimate bond strength and high shear holding power.
Q5: Is 3M 4016 suitable for high-temperature applications?
Yes, within its specified conditions. 3M’s current TDS reports static shear performance at temperatures up to 93°C and identifies long-term temperature holding capability up to 104°C (220°F).
Q6: Is 3M 4016 waterproof?
It should not be positioned as a waterproof tape. The current 3M product page recommends it for interior mounting and applications where the tape is protected from environmental exposure.
Q7: Can 3M 4016 be used outdoors?
It may be suitable for selected exterior applications when the tape is protected from direct environmental exposure. It should not be assumed to be a general-purpose outdoor weatherproof tape. Application testing is recommended.
Q8: What materials does 3M 4016 bond to?
It provides good adhesion to metals and high surface energy plastics, among other substrates. Actual adhesion depends on surface condition and preparation.
Q9: Can 3M 4016 be die-cut?
Yes. The product is suitable for industrial converting applications such as die-cutting and automated dispensing.
Q10: Can 3M 4016 be used for nameplates and signs?
Yes. 3M specifically lists mounting interior signs and nameplates among its recommended applications.
Q11: Does 3M 4016 help reduce vibration?
Yes. The urethane foam carrier can provide cushioning and vibration damping in suitable mounting applications.
Q12: Is 3M 4016 a VHB tape?
No. 3M™ Double Coated Urethane Foam Tape 4016 is not a 3M™ VHB™ Tape product. It belongs to the 3M Double Coated Urethane Foam Tape family and uses an open-cell polyurethane foam carrier with 3M Adhesive 100.
