Benefits
Excellent Bonding to Difficult Substrates
3M™ 9495LE is engineered for bonding challenging materials such as:
- Polypropylene (PP)
- Polyethylene (PE)
- Powder-coated metals
- Painted surfaces
- Textured plastics
The 300LSE adhesive chemistry provides superior surface wet-out and long-term adhesion.
High Mechanical Strength
The PET carrier improves dimensional stability and provides better handling performance compared with transfer adhesive tapes.
Suitable for applications requiring:
- High shear strength
- Long-term holding power
- Precise component positioning
Thin Permanent Bonding Solution
The thin construction helps maintain a low-profile assembly while replacing traditional mechanical fastening methods.
Excellent Die-Cutting Performance
3M™ 9495LE is suitable for precision converting processes:
- Custom adhesive gaskets
- Mounting pads
- Electronic component adhesives
- Functional adhesive parts
Technical Specifications
| Property | Specification |
|---|---|
| Product Name | 3M™ 9495LE Double Sided Tape |
| Tape Type | Double Coated Adhesive Tape |
| Adhesive Technology | 3M™ 300LSE Acrylic |
| Carrier | Polyester (PET) |
| Color | Clear |
| Total Thickness | Approx. 0.17 mm |
| Liner | Polycoated Paper Liner |
| Adhesion | Very High |
| Shear Strength | Excellent |
| Temperature Resistance | High |
| Moisture Resistance | Excellent |
| UV Resistance | Excellent |
| Processing | Slitting / Laminating / Die-Cutting |
Technical specifications should be confirmed according to the latest 3M™ technical data sheet.
Applications
Electronics
- Smartphone component assembly
- Battery component fixing
- Display module bonding
- Electronic housing assembly
- FPC and flexible component mounting
Automotive
- Interior trim attachment
- Emblem and badge mounting
- Plastic component bonding
- Sensor attachment
- Decorative parts assembly
Appliances
- Control panel mounting
- Plastic housing bonding
- Nameplate attachment
Industrial Assembly
- Industrial labels
- Sign mounting
- Foam bonding
- Gasket attachment
- Component fixing
Compatible Materials
| Material | Application |
|---|---|
| PP Plastic | Automotive components |
| PE Plastic | Industrial parts |
| ABS | Housing assembly |
| PC | Electronic components |
| PET Film | Lamination |
| Acrylic Sheet | Display parts |
| Aluminum | Metal bonding |
| Stainless Steel | Industrial assembly |
| Powder Coated Metal | Equipment panels |
| Painted Surfaces | Decorative applications |
Industries
- Consumer Electronics
- Automotive Electronics
- Electrical Appliances
- Medical Devices
- Industrial Equipment
- Display Manufacturing
- Renewable Energy
- Precision Manufacturing
Why Choose 3M™ 9495LE?
- Genuine 3M™ 300LSE acrylic adhesive technology
- Superior adhesion to low surface energy plastics
- High shear and peel strength
- Excellent environmental resistance
- PET carrier improves dimensional stability
- Suitable for precision die-cut parts
- Reliable replacement for screws, clips, and rivets
Guangdong Yousan provides:
- Custom roll widths
- Sheet conversion
- Precision die-cut adhesive components
- Multi-layer lamination
- OEM adhesive solutions
Installation Guide
- Clean the bonding surfaces using IPA or suitable cleaner.
- Remove dust, oil, and contaminants.
- Allow surfaces to dry completely.
- Apply tape without stretching.
- Apply firm pressure for good adhesive contact.
- Allow sufficient dwell time before loading.
- Test performance under actual application conditions.
Storage
Recommended storage conditions:
- Temperature: 15–25°C
- Relative Humidity: 40–60% RH
- Store in original packaging
- Avoid direct sunlight
- Keep away from moisture and heat sources
- Store rolls horizontally
- Follow FIFO inventory control
FAQ
What is 3M™ 9495LE used for?
3M™ 9495LE is used for permanent bonding of plastics, metals, films, and other materials, especially where strong adhesion to low surface energy surfaces is required.
What is the difference between 9495LE and 93015LE?
| Product | 3M™ 9495LE | 3M™ 93015LE |
|---|---|---|
| Structure | Double-coated tape | Adhesive transfer tape |
| Carrier | PET Film | None |
| Adhesive | 300LSE Acrylic | 300LSE Acrylic |
| Thickness | Approx. 0.17 mm | Approx. 0.15 mm |
| Dimensional Stability | Higher | Lower |
| Main Application | Structural component bonding | Thin adhesive transfer applications |
Can 3M™ 9495LE bond PP and PE?
Yes. The 300LSE acrylic adhesive is specifically designed for difficult-to-bond low surface energy materials.
Can 9495LE be die-cut?
Yes. The PET carrier provides excellent dimensional stability for high-precision die-cut adhesive parts.
Is 9495LE suitable for outdoor applications?
Yes. It offers excellent resistance to UV, moisture, and aging. Application testing is recommended for long-term outdoor exposure.
Downloads
Available upon request:
- 3M™ 9495LE Technical Data Sheet (TDS)
- Safety Data Sheet (SDS)
- Product Brochure
- Precision Die-Cutting Capability Guide
Please contact our sales team if you require the latest technical documentation.
