Ceramic Silicone Tape

Ceramic Silicone Tape is a high-performance insulating tape made of woven ceramic fibers coated with silicone adhesive. It offers excellent thermal resistance, electrical insulation, and durability under extreme conditions. Withstanding continuous temperatures up to 260°C (500°F) and short-term peaks up to 1000°C (1832°F), this tape is widely used for high-temperature insulation, thermal protection, and electrical applications.

Features:

High heat resistance with stable performance.
Strong electrical insulation properties.
Excellent flexibility and conformability.
Resistant to abrasion, chemicals, and aging.
Easy to apply and remove without leaving residues.
Certified UL94 VTM-0, ensuring excellent fire resistance and preventing flame propagation.

Applications:

Electrical insulation for high-temperature environments, Wrapping and protecting cables, wires, and hoses, Thermal insulation for furnaces, engines, and exhaust systems, Industrial equipment sealing and high-heat gasketing.

Additional Documents:

Ceramic Silicone Tape (TDS)

Adhesive Tapes Selection Guide

Technical data

Product Code / Technical Parameters	P114-20	P114-30	P114-50
Color	White, black, orange
Backing Thickness[mm]	0.2	0.3	0.5
hardness [SHA]	60
density [g/cm3]	1.6
Tensile Strength[Mpa]	15
tear strength [KN/m]	25
flame retardant	VTM-0 or V-0
volume resistivity [Ω·cm]	6.0*1012
High temperature insulation resistance (800 ℃)[Ω]	0.3*106
thermal conductivity [W/(m.K）]	＜0.5
dielectric strength [kV/mm]	20
Elastic retention temperature range[℃]	-55~+200

Legal Disclaimer

The values given are typical values, and do not constitute a specification. We recommend testing the suitability of the self-adhesive tape for the designated application or use. Please contact us or e-mail info@ysdiecut.com to determine product availability.

OEM: Delivers tailor-made adhesive tape products and die-cut components under your brand specifications—designed to integrate seamlessly into your end products.

ODM: Tape ODM (Original Design Manufacturing) refers to a service model where designs, develops, and manufactures ready-to-sell adhesive tape products that can be branded and marketed under your own label.

Die cutting tape are available in rolls, sheets, or custom-cut parts, tailored to a wide range of industry standards or customer-specific designs.

Ceramic Silicone Tape Manufacturer
Yousan New Materials

Storage
It is recommended to store in a clean and dry place, away from direct sunlight, to prevent damage to the packaging, and to avoid keeping it with volatile solvents. The storage temperature is 10-40°C and the humidity is 40-60%. To maintain optimal performance, this product should be used within 36 months from the date of manufacture.
