Aluminium Foil Tape

Aluminium foil tape is a versatile, high-performance adhesive tape made of a thin layer of aluminum foil coated with a strong pressure-sensitive adhesive. The aluminum backing provides excellent thermal conductivity, heat reflection, and moisture barrier properties, while also being flexible and conformable to irregular surfaces. This tape is widely used for sealing, patching, shielding, and insulation in HVAC, electronics, and industrial applications, thanks to its durability and resistance to temperature extremes, UV, and chemicals.

Features:

Excellent heat and light reflectivity.
High thermal conductivity for efficient heat transfer.
Strong adhesion to metal, plastic, and other surfaces.
Resistant to moisture, UV, and many chemicals.
Conformable to curved and irregular surfaces.

Applications:

Sealing and joining HVAC ducts and insulation materials, Heat shielding and light reflection in industrial and automotive applications, EMI/RFI shielding in electronic assemblies, Moisture and vapor barrier in construction and packaging, Temporary repairs on metal surfaces and pipes.

Additional Documents:

Aluminium Foil Tape (TDS)

Adhesive Tapes Selection Guide

Technical data

Product Code / Technical Parameters	P0605	P0606	P0607	P0608	P0610	P0612	P0614	P0615
Color	Silver White
Total Thickness [mm]	0.05	0.06	0.07	0.08	0.1	0.12	0.14	0.15
Backing Thickness [mm]	0.018	0.025	0.035	0.05	0.05	0.05	0.1	0.1
Backing	Aluminum foil
Adhesive	Acrylic
180°Peel Strength [N/inch]	12	12	12	12	12	12	13	15
Retentivity [hour]	12	12	12	12	12	12	12	12
Surface Resistance [mΩ]	50
Long-Term Temperature Resistance [℃]	80
Short-Term Temperature Resistance [℃]	120

Legal Disclaimer

The values given are typical values, and do not constitute a specification. We recommend testing the suitability of the self-adhesive tape for the designated application or use. Please contact us or e-mail info@ysdiecut.com to determine product availability.

OEM: Delivers tailor-made adhesive tape products and die-cut components under your brand specifications—designed to integrate seamlessly into your end products.

ODM: Tape ODM (Original Design Manufacturing) refers to a service model where designs, develops, and manufactures ready-to-sell adhesive tape products that can be branded and marketed under your own label.

Tapes Manufacturer
Yousan New Materials

Storage
It is recommended to store in a clean and dry place, away from direct sunlight to prevent damage to the packaging, and to avoid storing with volatile solvents. Store at 25±5°C and humidity at 50±5%.
