Benefits
- Reworkable Bonding: Supports applications where components may need to be separated or repositioned.
- Recycling Compatibility: Suitable for selected product designs requiring easier material separation.
- Reliable Adhesion: Provides high bonding strength on various substrates.
- Strong Shear Resistance: Helps maintain bond stability under shear loading.
- Clean Removal: Designed for residue-free removability under specified test conditions.
- Efficient Converting: Suitable for slitting, laminating, and precision die-cutting.
- Versatile Material Compatibility: Can be evaluated for metal, plastic, and foam bonding.
Technical Specifications
| Property | Typical Value |
|---|---|
| Product | Tesa 88648 |
| Product Type | Removable double-sided non-woven tape |
| Total Thickness | 160 μm |
| Color | Translucent |
| Backing Material | Non-woven |
| Adhesive Type | Tackified acrylic |
| Liner Type | PE-coated paper |
| Liner Color | White with blue logo |
| Elongation at Break | 25% |
| Tensile Strength | 15 N/cm |
| Tack | Good |
| Static Shear Resistance at 23°C | Very good |
| Removability After 14 Days at 23°C | Good |
| Residue-Free Removability | Yes |
| Short-Term Temperature Resistance | 130°C |
| Long-Term Temperature Resistance | 80°C |
Typical Adhesion Values
| Substrate | Initial Adhesion | After 3 Days | After 14 Days |
|---|---|---|---|
| Steel | 9 N/cm | 10 N/cm | 11 N/cm |
| ABS | 9 N/cm | 10 N/cm | — |
| PP | 6 N/cm | 7 N/cm | — |
The values are typical average results and are not guaranteed specifications. Removability and adhesive performance depend on substrate type, surface condition, bonding time, temperature, and removal method.
Applications
- Applications requiring re-peeling
- Recycling-oriented product assembly
- Reworkable component fixation
- Bonding of metal substrates
- Bonding of plastic substrates
- Foam material bonding
- Appliance and electronic component assembly
- Internal component fixation
- Seal material fixation
- Display and panel component mounting
- Foam and material lamination
- Custom adhesive component production
The documented application fields include applications requiring recycling or re-peeling, as well as bonding metal, plastic, and foam substrates.
Compatible Materials
Tesa 88648 can be evaluated for bonding the following materials:
- ABS
- Polypropylene (PP)
- Metal
- Steel
- Plastic components
- Foam materials
- Selected appliance materials
- Electronic component substrates
- Sealing materials
- Other compatible industrial substrates
Note: PP and other low-surface-energy materials require application-specific testing. Removability must be evaluated on the actual substrate and under the intended service conditions.
Industries
- Electronics and Electrical Components
- Home Appliance Manufacturing
- Battery and Energy Storage
- Automotive Components
- Plastic Product Manufacturing
- Foam and Sealing Material Converting
- Industrial Assembly
- Display and Panel Manufacturing
- Recycling-Oriented Product Design
- General Industrial Converting
Why Choose tesa 88648 from Yousan?
Yousan provides adhesive tape converting and customized processing services for industrial applications.
Our capabilities include:
- Custom roll slitting
- Precision die-cutting
- Kiss-cutting
- Laminating
- Custom widths and roll lengths
- Adhesive component converting
- Foam and plastic material lamination
- Customized adhesive shapes based on drawings
For tesa 88648, application validation should focus on the required bonding strength, removability, substrate compatibility, and recycling or rework process.
Installation Guide
1. Surface Preparation
Ensure the bonding surfaces are clean, dry, and free from dust, oil, grease, and other contaminants.
2. Check Removability Requirements
Confirm the required removal time, removal direction, substrate condition, and acceptable residue level.
3. Apply the Tape
Apply the tape evenly without stretching. Avoid wrinkles, air bubbles, and contamination of the adhesive surface.
4. Apply Firm Pressure
Use consistent pressure to improve adhesive contact and wetting on the substrate.
5. Allow Bond Development
Allow sufficient time for the adhesive to develop its bonding strength according to the application requirements.
6. Validate Removal Performance
Test the removal process on actual substrates. Check adhesive residue, substrate damage, deformation, and reworkability.
Storage
- Store in the original packaging.
- Keep the tape in a clean and dry environment.
- Protect it from direct sunlight and excessive heat.
- Avoid dust, moisture, and contamination.
- Follow the latest official tesa storage recommendations.
- Inspect the product before use after extended storage.
FAQ
1. What is tesa 88648?
Tesa 88648 is a 160 μm removable double-sided non-woven tape with a tackified acrylic adhesive.
2. Is tesa 88648 permanently removable?
It is designed for removability after bonding. Actual removal performance depends on the substrate, bonding time, temperature, and application conditions.
3. Is tesa 88648 suitable for recycling applications?
Yes. It is intended for applications requiring recycling or re-peeling.
4. Can tesa 88648 bond PP?
Typical adhesion data for PP is available. However, PP is a low-surface-energy material, so testing is recommended before production.
5. What is the thickness of tesa 88648?
The total tape thickness is approximately 160 μm.
6. What is the temperature resistance of tesa 88648?
The typical short-term temperature resistance is 130°C, and the long-term temperature resistance is 80°C.
7. Does tesa 88648 leave adhesive residue?
The product information indicates residue-free removability under specified test conditions. Actual results depend on the substrate and application conditions.
8. Can Yousan provide custom die-cut tesa 88648?
Yousan can evaluate custom slitting, laminating, and die-cutting according to the required dimensions, tolerances, and application.
Downloads
Available upon request:
- Tesa 88648 Technical Data Sheet (TDS)
- Safety Data Sheet (SDS)
- Product Brochure
- Precision Die-Cutting Capability Guide
Please contact our sales team if you require the latest technical documentation.
